APG-Advance Pressure Gauge

Overview

The APG Series High-Precision Digital Pressure Gauges are engineered to deliver exceptional measurement accuracy and long-term reliability for demanding industrial and laboratory applications. Available with accuracy classes of ±0.1%, ±0.05%, and ±0.02% of full scale, these gauges cover a comprehensive pressure range from –1 bar to 1000 bar, ensuring suitability for a wide spectrum of calibration and testing requirements.

A broad selection of pressure ranges allows users to choose the most appropriate configuration for their specific process or calibration needs. For enhanced usability, the gauge features 14 selectable engineering pressure units, along with convenient operational functions such as zero adjustment, tare setting, and peak hold display. These features allow users to perform accurate measurements under varying conditions while capturing maximum or minimum pressure values during dynamic testing.

With its robust construction, precision performance, and versatile configuration options, the APG Series provides a dependable solution for professionals who demand accuracy, repeatability, and confidence in their pressure measurement and calibration tasks.

APG-Applications

Master standard for calibration laboratories and quality assurance departments
Hydraulic and pneumatic pressure testing and verification
Field calibration and on-site validation of process instruments
Leak testing and pressure integrity testing of pipelines, valves, and vessels
Data logging and performance analysis of pressure systems over time
This gauge has options for calibrating through our ISO Calibration software
Research & development laboratories requiring high-accuracy pressure monitoring
Pharmaceutical and food industry process validation requiring traceable measurements

Pressure range	-1 to 1000 bar
Resolution	0.0001 to 0.1 bar
Accuracy	STD	LA	HA
	±0.1% of F.S	±0.05% of F.S	±0.02% of F.S
Special Functions (USER ADJUSTABLE)	Min/Max/ZERO/TARE/ LEAK TEST/DAMP/RESOLUTION DIGIT ADJUSTMENT/BL ADJUSTMENT
Storage Temperature	-20°C to 70°C
Operating Temperature	0 to 60°C
Pressure connection	1/4″ BSP (M)
Units (Depends upon ranges)	bar, psi, Kg/cm2, KPa, MPa, mmHg, atm, mH2O, inHg, inH2O, ftH2O, cmH2O, mbar, mmH2O
Protection	ABS Plastic with IP67
Power Supply	4 x AA battery
Pressure Media	All liquid and gas compatible with SS316
Battery Backup	2000 hours (STD), 400 hours (LA,HA)
Safety Standards	IEC 61000-4-2: Testing and measurement techniques – Electrostatic discharge immunity test. IEC 61000-4-3: Testing and measurement techniques – Radiated, radio-frequency, electromagnetic field immunity test
Certification	CE certified product
Data Logger	Data Output Format .TXT format via Serial Port Monitor Real-Time Clock (RTC) 24-hour internal clock Time Configuration: -User-Defined Date & Time Start Function Modes: – Immediate Start – Scheduled Start (date/time-based triggering) Logging Capacity by Up to 36,000 samples
Sensor	Gauge & Absolute
Over Pressure	120%FS up to 40 bar, 105%FS above 40 bar
Ideal	All process industries
